Building Your Own Laser or Replacing Your Laser Tube? Also Included in the video is How Install Water Protect & Ammeter Installation

DIY Laser Build installing the Co2 Laser Tube, Water Flow Protection Switch, Align Mirrors, Install a beam combiner kit, and test laser and Trocen AWC-708S controller using LightBurn Software. The main components I am using for this build are from Cloudray Laser –

A PDF Wiring Guide for the DIY Laser is available here – Laser Plans & Guides | MW Laser

Cloudray Analog Ammeter (Available in 0-30mA and 0-50mA) STORE | MW Laser

Click on the images below for more information.

The Mechanical parts I used for this Laser Build are from Cloudray – The size I am building 1300x900mm cutting area. It comes with all mechanical components, laser lens head, mirror mounts, tube mounts stepper motor mounts, axis rails and timing belt.

Thanks for Visiting.
Until next time, take care
Cheers Matthew
